UNS N04400 Nickel Alloy Steel Plate ASTM B127 Hot / Cold Rolled
1. MONEL 400 SHEETS
HT PIPE are manufacturers, stockists and suppliers of Monel 400 Sheets & Plates across India that is
fabricated from high quality raw materials. Monel 400 Sheets and Plates give great mechanical properties
over an extensive variety of temperature and brilliant resistance to numerous corrosives, specifically
hydroxides.
The Monel 400 Sheets & Plates manufactured by Speco Alloys Inc are known not only for its high quality
but greater strength. It works in wide ranges of temperatures, and is made available to our clients in
multiple forms and sizes according to their specifications and requirements.
2. MONEL 400 SHEETS & PLATES Specification
| Standard | ASTM B 127 / ASME SB 127 |
| Size | 15NB TO 150 NB IN |
| Grade | Monel 400 (UNS No. N04400) Sheets & Plates, 2.4360 |
| Type | Sheet, Plates, Coils, Flat, Strips, Profile, Blank ,Circle, Ring etc. |
| Form | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Application | Sulphuric Acid Production, Hydrochloric Acid Processes, Hydrofluoric & Fluorosilicic Acid Processes, Fatty Acid Production, Marine Industry and Shipbuilding,Propellers and Shafts, Fasteners, Oil and Gas Industry like Pumps, Valves, Crude Petroleum stills and process vessels, Heat Exchanger Plates. |
3. MONEL 400 SHEETS & PLATES Chemical Composition
| Element | Min | Max |
| Ni | 63.0 | 70.0 |
| Si | -- | 0.50 |
| Fe | -- | 2.50 |
| Cu | Remainder | Remainder |
| C | -- | 0.3 |
| S | -- | 0.024 |
| Mn | -- | 2.00 |
4. MONEL 400 SHEETS & PLATES Mechanical Properties
| Product Form | Tensile (ksi) | .2% Yield (ksi) | Elongation % | Hardness (HRb) |
| Rod & Bar | 75 to 90 | 25 to 50 | 60 to 35 | 60 to 80 |
| Plate | 70 to 85 | 28 to 50 | 50 to 35 | 60 to 76 |
| Sheet | 70 to 85 | 30 to 45 | 45 to 35 | 65 to 80 |
5. MONEL 400 SHEETS & PLATES Physical Properties
| Density@ Room Temp | 0.318 lb/in3 |
| Elastic Modulus @ 70ºF (tension) | 26.0 x 106psi |
| Specific Heat @ 70°F | 0.102 Btu/lb/°F |
| Melting Point | 2370°F to 2460°F |
| Thermal Conductivity @ 70°F | 151 Btu • in/h/ft 2 /°F |
| Electrical Resistivity @ 70°F | 0.511 μ Ω • m |
6. MONEL 400 SHEETS & PLATES EXPORTS
Speco Alloys Inc exports MONEL 400 SHEETS & PLATES MANUFACTURER AND EXPORTER to
Dubai, Sharjah, Abhdhabi, Oman, Qatar, Saudi Arabia, Kuwait, Iran, Iraq, Malaysia, Indonesia, Norway,
Nigeria, Algeria, Egypt, Libya, Brazil, Angola, Guinea, Mozambique, Tanzania, Venezuela, Canada,
Ecuador, Ghana, Vietnam, Trinidad And Tobago, Thailand, Korea, Taiwan, Australia, Italy, France, Spain,
Russia, Germany & Azerbaijan countries.
Product Tags:
|
|
ASTM B127 UNS N04400 Nickel Alloy Steel Plate High Toughness For Heat Exchanger Images
|
